TSX88HS
TSX88HS Surface Mount Momentary Switch:
TSX88HS is an on/off electronic surface mount momentary switch that is only on when the button is pressed or if there is a definitive change in pressure.
It was used for circuit board, the height for the switch is 5.5mm.
The Tactile Switch applications include: Low power, miniature devices, digital switching, anything where operator feedback is required (a switch confirmation coming from the switch being depressed) will find that the perfect choice is a Tactile switch.
Pls check the datasheet below:
| Type: | Snap-in | Operating force: | 120±40gf |
| Operating Direction: | Top Push | Travel: | 0.25mm |
| Operating Life: | Over 50,000 cycles | Initial contact resistance: | 200mΩ max. |
| Stem color: | Black | Operating Temperature: | -25℃~+70℃ |
| Stem height: | H=5.5mm | Series type: | Sharp feeling type |
| Rating (max.): | 50mA 12V DC | Rating (min.): | 10µA 1V DC |
| SPQ: | 1,000pcs | OEM or ODM: | Available |
