KW10-Z0P micro switch mouse:

KW10-Z0P mouse micro switch is rated for controlling electrical loads ranging from logic-level/computer-based circuits to limited power-duty switching (up to 3 A/125 Vac). KW10-Z0P micro switch package is available with either solder terminals or a variety of different styles of printed circuit board (PCB) terminals to fulfill the requirements for electrical connectivity.

Pls check the datasheet below:



Housing: Nylon 66 Lever length: 0 mm
Terminal Brass with sliver plated Switch Operation: OFF – momentary ON
Contact Configuration: SPDT Operating Temperature: -25℃~+75℃
Rating: 1A 250VAC/3A 125VAC Ambient Temperature Used: 〈85% RH
Contact Resistance: ≤30mΩ Electrical Life: ≥ 10,000 Cycles
Insulation Resistance: ≥100mΩ (500VDC) Mechanical Life: ≥ 100,000 Cycles
Dielectric strength: 1500VAC 1 minute OEM or ODM: Available
KW10 mouse micro switch
